55UL3J-E
55UL3J-E webOS UHD Signage
Key Features
- Brightness(Typ.) : 400 nits
- Resolution : ULTRA HD (3,840 x 2,160)
- webOS-based High Performance
- Built-in Speaker
- Compatible with LG's One:Quick Share
- Compatible with AV Control Systems
Contact us
GGEAR Commercial
LG webOS™ UHD Signage
Sophisticated Slim Design
This series is thin in bezel size and thickness*, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed.
Superb Picture Quality with Ultra HD Resolution
Ultra-HD resolution (3,840 x 2,160) and LG's IPS screen technology combine to deliver content with rich color and detail for a realistic image. IPS screens also provide a wide viewing angle for off-axis viewing.
Remote Monitoring and Control
A user-friendly web-based monitoring solution enables the user to have full access to the display anywhere at any time from their mobile phone & PC under a network-accessible environment while having access to both current and past data. It also allows the user to monitor the display, make adjustments and control the unit remotely in real-time.
LG's Simple Advertisement Helper, Promota
Using LG's Promota* application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more to your customers while recommending easy-to-use templates relevant to your industry.
Compatible with AV Control Systems
For added efficiency, the UL3J series supports Crestron Connected®* for compatibility with professional AV controls to achieve virtually seamless integration and control**.
Compatible with Video Conference System
For compelling video conferencing, the UL3J series is compatible with Cisco® solutions that offer robust and integrated control* for an intelligent video conference.
Easy Menu Setup for Vertical Needs
Easy Menu Setup for Vertical Needs
Wireless Access Point
UL3J series operates as a virtual router which can be an wireless access point for mobile devices.
High Performance with LG webOS 6.0
LG webOS 6.0, upgraded in SoC* and web engine, is available on UL3J series for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI.**
Various Sensor Connection
LG webOS smart signage platform helps to easily provide value-added solutions* by supporting simple connections with external sensors** such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Built-in Speaker
Built-in speakers eliminate the need for external speakers and deliver clear, crisp sound.
Easy Content Distribution & SW Update
UL3J series features embedded Wi-Fi making it easy to distribute content wirelessly and update firmware under the same network.
Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnecedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and provides remote-control services that support the stable operation of clients' businesses.
EPEAT Registered
The Electronic Product Environmental Assessment Tool (EPEAT) is a method to evaluate the effect of a product on the environment. UL3J is EPEAT Bronze certified* display which means that it meets all the required criteria in Computers and Displays category.
size
55
Native Resolution
3840 x 2160 (UHD)
Contrast Ratio
1,300:1
Color gamut
DCI 80%
Color Depth
1.07G (8bits + FRC)
Surface Treatment(Haze)
3%
Portrait / Landscape
Yes / Yes
Panel Technology
ADS
Brightness
400nits
Dynamic CR
1,000,000:1
Response Time
8ms (G to G)
Operation Hours (Hours/Day)
16/7
Refresh Rate
60Hz
Bezel Color
Ashed Blue
Bezel Width
Off : 6.9/6.9/6.9/18.4 On : 12.8/12.8/12.8/19.9
Weight(Head)
14.0 kg
Dimension(W x H x D)
1,235 x 715 x 57.5 mm
VESA<sup>TM</sup> Standard Mount Interface
300 × 300 mm
Handle
No
Carton Dimensions (W × H × D)
1,360 x 810 x 162 mm (Box outer size)
Input
HDMI (3, HDCP 2.2 / 1.4), USB 2.0 Type A (2)
Output
Audio
External Control
RS232C In / Out (4 Pin Phone Jack), RJ45 (LAN) In
Operation Humidity
10 % to 80 %
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ.)
105 W
Power Consumption (Max.)
160 W
BTU (British Thermal Unit)
273 BTU/Hr(Typ.), 409 BTU/Hr(Max.)
Operation Temperature
0 °C to 40 °C (Portrait Scene : 0 °C to 35 °C)
Safety
CB / NRTL
EMC
FCC Class "A" / CE
ErP
Yes (NewErP)
SuperSign CMS
Yes
SuperSign Media Editor
Yes
SuperSign Control / Control+
Yes
SuperSign WB
Yes
LG ConnectedCare
Yes
Promota
Yes (Not available for EU/CIS)
Speaker
Yes
Basic
Remote Controller(include battery 2ea), Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder
