Screen Size (Inch)

55"

Panel Technology

IPS

Back Light Type

Direct

Aspect Ratio

16 : 9

Native Resolution

3,840 x 2,160 (UHD)

Refresh Rate

60Hz

Brightness

w/o Glass : 411 nit (Max.), 311 nit (Typ.) w/ Glass : 380 nit (Max.), 280 nit (Typ.)

Contrast Ratio

1,200:1

Color gamut

NTSC 68%

Viewing Angle(H x V)

178 X 178

Color Depth

10bit, 1.07Billion colors

Response Time

8 ms (G to G)

Surface Treatment (Haze)

Anti Glare, 7H (Mohs)

Life time

30,000 Hrs (Min.)

Operation Hours (Hours/Day)

16 / 7

Portait / Landscape

No / Yes

Input

HDMI (3, HDCP2.2/1.4), RGB, Audio In, RS232C IN, RJ45(LAN), USB3.0 Type A(3), USB2.0 Type A(3)

Output

HDMI Out, Audio Out, Optical Output, Touch USB (2)

Bezel Color

Black

Bezel Width

18.9 / 18.9 / 18.9 / 45.7 mm

Weight (Head)

27 kg

Packed Weight

45.7 kg

Monitor Dimensions (W x H x D)

1,271 x 774 x 84 mm

Carton Dimensions (W x H x D) (Box outer size)

1,450 x 1,015 x 225 mm

VESA™ Standard Mount Interface

400 x 200

HW - Internal Memory

16GB

HW - Wi-Fi - Built-in

Yes (Slot type)

HW - Power Indicator

Yes

HW - Local Key Operation

Yes

SW - webOS ver.

Android 8.0

SW - Screen Share

Yes (Screenshare pro)

Operation Temperature

0 °C to 40 °C

Operation Humidity

10 % to 90 %

Power Supply

AC 100-240V~, 50/60Hz

Power Type

Built-In Power

Typ.

125 W

Max.

259 W

BTU (British Thermal Unit)

427 BTU/Hr (Typ.), 884 BTU/Hr (Max)

DPM

0.5 W↓

Power off

0.5 W↓

Speaker

Yes

Safety

CB / NRTL

EMC

FCC Class "A" / CE

ErP

Yes

OPS Type Compatible

Yes (Slot)

OPS Power Built In

Yes

Basic

Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender

Optional

OPS Kit (KT-OPSF)

Touch - Available object size for touch

Ø3 mm ↑

Touch - Reponse Time (PC Win10)

60 ms ↓ (Android) 100 ms ↓ (Windows)

Touch - Accuracy

±1.5 mm

Touch - Interface

USB2.0

Touch - Protection Glass Thickness

3T (Anti-Glare)

Touch - Protection Glass Transmission

87%

Touch - Operating System Support

Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)

Touch - Multi touch point

Max. 20 Points

SoC

Dual core A73+Dual core A53

GPU

Dual Core Mail G51

Internal Memory - Storage

16GB

Internal Memory - RAM

3GB

Wi-Fi

802.11a/b/g/n/ac

LAN

Gigabit LAN

Bluetooth

Bluetooth 4.0
