75UH5J-M
New High Haze UHD Standard Signage
Key Features
- Brightness (Typ.) : 500 nit
- Surface Treatement (Haze) : 28%
- Bezel : 14.9 mm (Even bezel)
- Depth : 57.9 mm
- Interface : HDMI(3) / DP / DVI-D / USB 2.0 / RS232C / RJ45 / Audio / IR
- Built-in Speaker
Contact us
GGEAR Commercial
New High Haze UHD Standard Signage
Adequate Brightness Level
The 75UH5J-M series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.
Mobile Content Management
You can create a store profile and get template recommendations using the Promota* app. Users can customize templates as needed and easily create and manage content not only on PCs but also on mobile devices.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.
Compatible with AV Control System
The 75UH5J-M series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
Product
Standard (UHD)
Year
Y22
Month
M06
Screen Size (Inch)
75
Panel Technology
IPS
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120 Hz
Brightness (Typ.)
500nit (Typ.)
Contrast Ratio
1,000:1
Dynamic CR
1,000,000:1
Color gamut
NTSC 72%
Viewing Angle (H x V)
178 Deg.(H) x 178 Deg.(V)
Color Depth
10 bit(D), 1.07 Billion colors
Response Time
6ms (G to G)
Surface Treatment(Haze)
Haze 28%
Life time
50,000 Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portrait / Landscape
Yes / Yes
HDMI IN
Yes(3) HDMI1/HDMI2 : HDCP 2.2/1.4 HDMI3 : HDCP 1.4
DP IN
Yes(1), HDCP2.2/1.3
DVI-D IN
Yes(1), HDCP1.4
Audio IN
Yes (1)
RS232C IN
Yes(1), 4pin Phone-jack
RJ45 (LAN) IN
Yes (1)
IR IN
Yes (1)
USB IN
USB 2.0 Type A (1)
HDMI Out
Yes (1)
Audio Out
Yes (1)
RS232C Out
Yes (1), 4PIN Phone-Jack
Daisy Chain
Yes (Input HDMI, DP / Output HDMI)
Bezel Color
Black
Bezel Width
Even bezel: 14.9mm
Weight (Head)
41.5Kg
Packed Weight
51.2Kg
Monitor Dimension (W x H x D)
1682.4 x 960.3 x 57.9mm (without Handle and LG Logo)
Carton Dimensions(W x H x D)
1816 x 1123 x 228mm
Handle
Yes
VESATM Standard Mount Interface
600 x 400
Internal Memory (eMMC)
16GB
Wi-Fi (Built-in)
Yes
Temperature Sensor
Yes
Auto Brightness sensor
Yes
Acceleration (Gyro) Sensor
Yes
Local Key Operation
Yes
Speaker (Built-in)
Yes
OS ver.
webOS 6.0
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail Over
Yes
Booting Logo Image
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
PIP
Yes
PBP
Yes (4)
Screen Share
Yes
Video Tag
Yes (4)
Play vai URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes (Max. 15x15)
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Crestron Inside
Yes
Smart Energy Saving
Yes
PM Mode
Yes
Wake on LAN
Yes
Network Ready
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Pro:ldiom
Yes
Operation Temperature
0 °C to 40 °C
Operation Humidity
10%～80%
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power
Power Consumption (Typ.)
170W
Power Consumption (Max.)
230W
Power Consumption (Max.)
581 BTU/Hr(Typ.), 785 BTU/Hr(Max)
Power Consumption (Smart Energy Saving, ~70%)
120W
Power Consumption (DPM)
0.5W
Power Consumption (Power Off)
0.5W
Safety
CB / NRTL
EMC
FCC Class"A" / CE / KC
ErP / Energy Star
Yes (NewErP) / Yes
OPS Type Compatible
Yes
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign WB
Yes
SuperSign Cloud
Yes
Promota
Yes (Not available for EU/CIS)
Mobile CMS
Yes
Connected Care
Yes
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
Optional
OPS Kit(KT-OPSF), LSW640A/B(Wall Mount)
Conformal Coating (ower Board)
Yes
