Pixel Configuration

3 in 1 SMD

Pixel Pitch (mm)

0.938

Module Resolution (W × H)

160 × 360

Module Dimensions (W × H, mm)

150 × 337.5

Weight per Module (kg)

0.50

No. of Modules per Cabinet (W × H)

4 × 1

Cabinet Resolution (W × H)

640 × 360

Cabinet Dimensions (W × H × D, mm)

600 × 337.5 × 56

Cabinet Surface Area (m²)

0.203

Weight per Cabinet (kg/Cabinet)

6.0

Weight per Square Meter (kg/m²)

30.0

Physical Pixel Density (pixels/m²)

1,137,777

Flatness of Cabinet (mm)

0.5

Cabinet Material

Die Casting Aluminum

Service Access

Front

Max. Brightness (nit, after calibration)

600

Color Temperature (K)

3,200-9,300

Visual Viewing Angle (H × V)

160 × 140

Brightness Uniformity

97%

Color Uniformity

±0.003 Cx,Cy

Contrast Ratio

5,000 : 1

Processing Depth (bit)

16 (HDR10, HDR10 Pro)

Power Consumption (W/screen, Max.)

120

Power Consumption (W/screen, Avg.)

40

Power Consumption (W/m², Max.)

600

Power Consumption (BTU/h/Screen, Max.)

409

Power Consumption (BTU/h/Screen, Avg.)

136

Power Consumption (BTU/h/㎡, Max.)

2,047

Power Supply (V)

AC 100-240 V (50-60 Hz)

Frame Rate (Hz)

50 / 60

Refresh Rate (Hz)

3,840

Lifetime (Hours to Half Brightness)

100,000

Operating Temperature (°C)

-20 to +40

Operating Humidity

10-80% RH

IP Rating (Front / Rear)

IP5X / IP5X

Certification

CE,FCC,ETL,CB

Environment

RoHS, REACH

Controller

Embedded
